Fujitsu ARTG36LHTDP 10.0kW Slimline Plus Ducted Air Conditioner

by Fujitsu


  • High static allows for an increased number of air ducts to be installed
  • Optional zone control allows for 8 zones to be connected, giving greater temperature control to meet individual needs
  • Use of single phase power allows for greater installation flexibility
  • Slim and compact design to fit into most ceiling spaces, making it ideal for apartment and hotel use
  • Operated from an easy to use central LCD control
  • Multiple features such as DC fan motors, DC rotary compressors and programmable systems deliver high energy efficiency

INTUITIVE CONTROL Operated from an easy-to-use LCD control, you can change the settings for mode, fan speed and set temperature and also program the weekly timer to maintain temperature with minimal fuss.

QUIET AND EFFICIENT Quiet, efficient and easy to maintain, offering perfect comfort for the room it is installed in.

COMPACT AND FLEXIBLE DESIGN Slimline type ducted air conditioners are slim and compact in design in order to fit into most ceiling spaces, making it ideal for installation to be discreet. The adjustable static feature along with optional zone controller connectivity allows greater flexibility with installation and adjustable airflow for improved comfort.

Specification :

Outdoor AOTG36LBTA
Operation Type   Reverse Cycle
Power Source V / ø / Hz 240 / 1 / 50
Capacity (Min - Max) Cooling kW 10.00 (3.80 - 11.20)
Heating kW 11.20 (4.00 - 14.00)
Input Power Cooling kW 3.11 (Max 4.78)
Heating kW 3.07 (Max 4.76)
Rating Cooling EER 3.22
AEER 3.24
Heating COP 3.65
ACOP 3.73
Running Current Cooling A 13
Heating A 12.9
Moisture Removal L / Hr 2.4
Noise Level Indoor Sound Pressure (High / Quiet) dBA 36 / 26
Outdoor Sound Pressure dBA 54
Outdoor Sound Power dBA 70
Static Pressure Range PA 30 to 200
Air Circulation (Indoor - High Fan) L / s 569
Dimensions HxWxD Indoor mm 300 x 1400 x 700
Outdoor mm 830 x 900 x 330
Weight Indoor kg 46
Outdoor kg 61
Piping Connections (Liquid / Suction) mm ø9.52 / ø15.88
Max. Pipe Length (Precharged Length) m 50 (20)
Max Height Difference m 30
Operation Range Cooling °CDB -10 to 46
Heating °CDB -15 to 24
Refrigerant   R410A
